Descripción
The NCV8452 is a fully protected high-side driver that can be used to switch a wide variety of loads, such as bulbs, solenoids and other activators. The device is internally protected from an overload condition by an active current limit and thermal shutdown.
Short Circuit Protection
Thermal Shutdown with Automatic Restart
CMOS (3 V/5 V) Compatible Control Input
Overvoltage Protection and Shutdown
Output Voltage Clamp for Inductive Switching
Under Voltage Shutdown
Loss of Ground Protection
ESD Protection
Reverse Battery Protection (with external resistor)
Very Low Standby Current
NCV Prefix for Automotive and Other Applications Requiring
Unique Site and Control Change Requirements
PPAP Capable
End Products
Automobiles
Applications
Switch a Variety of Resistive, Inductive and Capacitive Loads
Replace Electromechanical Relays and Discrete Circuits
| Atributo | Valor |
|---|---|
| Tipo de Montaje | Montaje superficial |
| Tipo de Encapsulado | SOT-223 |
| Conteo de Pines | 4 |
| Dimensiones | 6.7 x 3.7 x 1.75mm |
| Longitud | 6.7mm |
| Ancho | 3.7mm |
| Altura | 1.75mm |
| Tensión de Alimentación Máxima de Funcionamiento | 34 V |
| Temperatura Máxima de Funcionamiento | +150 °C |
| Tensión de Alimentación de Funcionamiento Mínima | 5 V |
| Temperatura de Funcionamiento Mínima | -40 °C |
| Estándar de automoción | AEC-Q101 |
