Descripción
1N5221B: Zener 2.4V 0.5W 5%
General Data Applicable to all series in this group.
500 Milliwatt
Hermetically Sealed
Glass Silicon Zener Diodes
Complete Voltage Range – 1.8 to 200 Volts
DO-204AH Package – Smaller than Conventional DO-204AA Package
Double Slug Type Construction
Metallurgically Bonded Construction
Mechanical Characteristics:
CASE: Double slug type, hermetically sealed glass
MAXIMUM LEAD TEMPERATURE FOR SOLDERING PURPOSES: 230?C, 1/16″, from case for 10 seconds
FINISH: All external surfaces are corrosion resistant with readily solderable leads
POLARITY: Cathode indicated by color band. When operated in zener mode, cathode will be positive with respect to anode
MOUNTING POSITION: Any
WAFER FAB LOCATION: Phoenix, Arizona
ASSEMBLY/TEST LOCATION: Seoul, Korea
| Atributo | Valor |
|---|---|
| Tensión Nominal de Zener | 2.4V |
| Configuración de diodo | Simple |
| Tipo de Montaje | Montaje en orificio pasante |
| Número de Elementos por Chip | 1 |
| Disipación de Potencia Máxima | 500 mW |
| Tipo de Encapsulado | DO-35 |
| Tipo de Zener | Uso general |
| Tolerancia de Tensión de Zener | 5% |
| Conteo de Pines | 2 |
| Corriente de Prueba | 20mA |
| Impedancia Máxima de Zener | 1200 Ω @ 0.25, 30 Ω @ 20 mA |
| Corriente de Fugas Inversa Máxima | 100µA |
| Dimensiones | 1.91 (Dia.) x 4.56mm |
| Temperatura Máxima de Funcionamiento | +200 °C |
| Coeficiente de Temperatura de Tensión Típica | -0.085%/°C |
| Corriente directa | 200mA |
| Tensión directa | 1.2V |
| Temperatura de Funcionamiento Mínima | -65 °C |
