Descripción
With the ever-pressing need to improve power supply efficiency, improve surge rating, improve reliability, and reduce size, the DFxS1 family sets a new standard in performance and cost saving. The DFxS1 family balances performance against cost. The design offers a moderate surge rating of 35 A required to handle inrush surge and maintain good reliability, with fair price. The DFxS1 achieves good performance in a SDIP surface mount form factor, reducing board space and volumetric requirements vs. competitive devices.
Maximum Surge Rating: IFSM = 35 A, I2t = 5.1 A2Sec
Optimized VF: Typical 0.95 V at 1 A, 25°C
DF10S Socket Compatible
Glass Passivated Junctions
Space Saving
Lead Free
Green Molding Compound: Halogen Free
Qualified with IR Reflow and Wave Soldering
| Atributo | Valor |
|---|---|
| Corriente Directa Media de Pico | 1A |
| Tipo de Puente | Monofásico |
| Tensión Repetitiva Inversa de Pico | 800V |
| Tipo de Montaje | Montaje superficial |
| Tipo de Encapsulado | SDIP |
| Conteo de Pines | 4 |
| Configuración | Único |
| Transitorios de corriente directa no repetitiva de pico | 35A |
| Temperatura Máxima de Funcionamiento | +150 °C |
| Temperatura de Funcionamiento Mínima | -55 °C |
| Tensión Directa de Pico | 1.1V |
| Corriente Inversa de Pico | 500µA |
| Longitud | 8.51mm |
| Dimensiones | 8.51 x 6.5 x 2.6mm |
| Altura | 2.6mm |
| Capacitancia de unión | 10pF |
| Ancho | 6.5mm |
