Descripción
Relés de supervisión K8AK-PW/PM/PH/PA de Omron
Los relés de supervisión de la serie K8AK de Omron están diseñados por expertos para lograr un control preciso y fiable de los equipos e instalaciones industriales.
Los relés de supervisión K8AK-PW/PM se han diseñado para ofrecer mayor resistencia al ruido, por lo que son adecuados para el control de fuentes de alimentación trifásicas.
Los relés K8AK-PH son ideales para prevenir cuestións relacionados con el funcionamiento del motor y facilitan la detección de pérdidas de fase.
Los relés K8AK-PA son adecuados para el control de asimetría de tensión trifásica.
K8AH-PA2 Monitoring Relay.
• Resistant to inverter noise.
• Monitor voltage asymmetry, phase sequence plus phase loss for three-phase 3-wire or 4-wire power supplies with one unit.
• Switch setting for 3-phase 3-wire or 3-phase 4-wire power supply.
• One SPDT output relay, 5 A ate 250 V ac (resistive load).
• Global power specification supported by one unit. (Switching)
• Relay status monitored by using LED indicator.
K8AK-PA2 Model.
K8AK-PA2 380480VAC.
3-phase, 3-wire model.
380 V ac, 400 V ac, 415 V ac, 480 V ac.
Three-phase. Three-wire or four-wire input ranges are switched using a DIP switch.
Power supply voltage is the same as the rated input voltage.
Features and Benefits.
• Input load 4.4 VA.
• Automatic reset method.
• Power on LOCK time 1 s/5s (changed with the DIP Switch).
• One SPDT relay NC (normally closed).
• Power (PWR) indicator – Green.
• Relay (RY) output – Yellow.
• Alarm (ALM) output – Red.
• Case is PC and ABS, UL 94-V-0, N1.5.
• Weight 130 g.
• DIN Rail mounted.
What is a Monitoring / Measuring Relay?
A monitoring / measuring relay is a protective control device, various types are available suiting what you wish to monitor. The relays receive input signals then monitor them and then output an alarm signal when a set value is reached (alarm relays). The relays protect your equipment against over voltage and over current faults. Monitoring relays monitor AC power supplies, voltage and current, analogue signals detecting unusual activity in equipment against set alarm thresholds.
Types of Monitoring Relays Available?
• Motor protection relays
• Temperature monitoring relays
• Water level control relays
Estándares
EN 60947-5-1, UL 508, IP 20.
| Atributo | Valor |
|---|---|
| Aplicaciones de Monitorización | Fase |
| Fase Eléctrica | 3 |
| Configuración de los Contactos | SPDT |
| Tipo de Montaje | Carril DIN |
| Sensibilidad de Fase | Asimetría de Fase, Pérdida de Fase, Secuencia de Fase |
| Retardo | 0.1 → 30s |
| Serie | K8AK-PA |
| Dimensiones | 100 x 22.5 x 90mm |
| Temperatura de Funcionamiento Máxima | +60°C |
| Anchura | 22.5mm |
| Temperatura de Funcionamiento Mínima | -20°C |
| Longitud | 100mm |
| Altura | 90mm |
| Rango de Temperatura de Funcionamiento | +60°C |
| Tipo de Terminal | Roscado |
